Features of the SA Series precision planetary reduction gears for servomotors (ServoAce)
High rigidity |
This tough construction is capable of withstanding high frequency starting and stopping. |
High accuracy |
This series features the low backlash required for accurate positioning. |
Low noise |
Quiet design is made possible by smooth torque transmission. |
High strength |
The internal gear is manufactured of steel and features a strong integrated design with the housing. The output shaft attachment flange is manufactured of tough cast-iron, offering high rigidity. |
Precise |
The planetary and sun gears undergo grinding after carburizing and quenching. Internal gears undergo highly precise broaching. Noise is 60 dB or less and backlash is 15 minutes. *Backlash is a value measured at 2% of the rated torque. |
Space saving |
The corner flange saves space for attachment. |
A rich variety of production ratios |
Single speed - 5 varieties, double speed - 6 varieties |
Easy motor installation |
The servomotor can be easily installed with bolts and after the shaft has been pressed-in, it is tightened down by bolts. |
Lubrication |
Grease for precision machinery (Maintenance-free) |
Prime specifications of SA Series precision planetary reduction gears for servomotors (ServoAce)
| Materials | Casing (Internal gear) | Cr-Mo steel (Thermal refined) |
|---|---|---|
| Planet/Sun | Carburized steel | |
| Input-side cover | Aluminum | |
| Output-side cover | Spheroidal graphite cast iron | |
| Paint color | Mansel 5.5PB5.5/9 sky-blue (lacquer) | |
| Grease | Kyodo Yushi Co., Ltd., Marutemp AC-D | |
| Input shaft speed | 3000 RPM* | |
*Please consult with Makishinko when the input rotational speed exceeds 3,000 rotations.
Structure of the SA Series precision planetary reduction gears for servomotors (ServoAce)
Figure 1 The structure of SA Series precision planetary reduction gears for servomotors (ServoAce)
Figure 2 Nomenclature of SA Series (ServoAce) precision planetary reduction gears
