The package of 30W DC brushless motor and 24V input compact motor driver. Operable in 90 - 3,000 r/min and excellent velocity control stability.
Depending on the applications and torque requirement, motor is selectable from round shaft type and geard type 1:5 to 1:100 wide gear ratio lineup.

• Wide velocity range. Operable in 90 - 3,000 r/min (velocity ratio 1 : 33)
• Extremely compact and light design motor driver
• Excellent velocity control stability : velocity fluctuation 0.5% or less
• 2 velocities setting function by internal potentiometer and external DC power input
• Safe start function for safe operation
• Acceleration / Deceleration time setting and instantaneous stop function
• Monitoring motor velocity by rotation pulse output signal
• Protective functions : Excessive load, excessive velocity, overheat, excessive voltage and low voltage
• 1:5 to 1: 100 wide gear ratio lineup
• Available power supply unit package (Optional)

Excellent velocity control stability (0.5% or less) even with load, temperature or input voltage fluctuations. Safe start function works to avoid unexpected sudden acceleration by load fluctuation.
