E-Catalog > Stepping Motor & Driver > CSA-BB Series
Product Detail :
Line up
High Power Microstepping Driver & Stepping Motor Package
 |
The package of 2 phase stepping motor and Max.48V input / 6A output high power bipolar stepping motor driver capable 1/16 microstepping driving. High voltage driving improves motor torque performance at high frequency. Depending on the applications and torque requirement, motor is selectable high frequency running motor from size 42mm(NEMA17),56.4mm(NEMA23) and 60mm(NEMA24) lineup.
|
Product Lineup
![Size [mm]](http://www.skcj.co.jp/plexmotion/english/img/content/th_cel1.gif) |  | ![Rated Current [A]](http://www.skcj.co.jp/plexmotion/english/img/content/th_cel4.gif) | ![Holding torque [mN-m]](http://www.skcj.co.jp/plexmotion/english/img/content/th_cel5.gif) | ![Motor length, [mm]](http://www.skcj.co.jp/plexmotion/english/img/content/th_cel6.gif) | ![Motor mass [kg]](http://www.skcj.co.jp/plexmotion/english/img/content/th_cel7.gif) |  | ||
|---|---|---|---|---|---|---|---|---|
 |  |  | ||||||
| 42 | CSA-BB42D1 | 1.6 | 0.291 | 34.0 | 0.23 |  |
 |
 |
| 42 | CSA-BB42D2 | 1.6 | 0.417 | 40.0 | 0.29 | |
|
|
| 42 | CSA-BB42D3 | 1.6 | 0.536 | 47.5 | 0.36 | |
|
|
| 56.4 | CSA-BB56D1 | 2.8 | 0.847 | 42.0 | 0.51 | |
|
|
| 56.4 | CSA-BB56D3 | 2.8 | 1.376 | 54.5 | 0.71 | |
|
|
| 56.4 | CSA-BB56D5 | 2.8 | 2.424 | 77.5 | 1.11 | |
|
|
| 60 | CSA-BB60D1 | 2.8 | 1.165 | 46.3 | 0.62 | |
|
|
| 60 | CSA-BB60D3 | 2.8 | 1.647 | 55.8 | 0.88 | |
|
|
| 60 | CSA-BB60D5 | 2.8 | 3.106 | 87.8 | 1.40 | |
|
|
*Please refer the attention before starting download service
(2D data and 3 data are compressed by zip format)
| | | | | | | ||
|---|---|---|---|---|---|---|---|---|
| | | ||||||
| 42 | CSA-BB42D1D | 1.6 | 0.291 | 34.0 | 0.23 | |
|
|
| 42 | CSA-BB42D2D | 1.6 | 0.417 | 40.0 | 0.29 | |
|
|
| 42 | CSA-BB42D3D | 1.6 | 0.536 | 47.5 | 0.36 | |
|
|
| 56.4 | CSA-BB56D1D | 2.8 | 0.847 | 42.0 | 0.51 | |
|
|
| 56.4 | CSA-BB56D3D | 2.8 | 1.376 | 54.5 | 0.71 | |
|
|
| 56.4 | CSA-BB56D5D | 2.8 | 2.424 | 77.5 | 1.11 | |
|
|
| 60 | CSA-BB60D1D | 2.8 | 1.165 | 46.3 | 0.62 | |
|
|
| 60 | CSA-BB60D3D | 2.8 | 1.647 | 55.8 | 0.88 | |
|
|
| 60 | CSA-BB60D5D | 2.8 | 3.106 | 87.8 | 1.40 | |
|
|
*Please refer the attention before starting download service
(2D data and 3 data are compressed by zip format)
Specification details
High Power Microstepping Driver & Stepping Motor Package
High Power Microstepping Driver (Bipolar)：PDSA-BB
 |
|
2 phase stepping motor
| 42mm motor(NEMA17) | 56.4mm motor(NEMA23) | 60mm motor(NEMA24) |
|---|---|---|
 |
 |
 |
| Step angle | 1.8deg |
|---|---|
| Winding type | Bipolar |
| Shaft type | Single shaft / Double shaft |
| Rated current | 1.6 - 2.8A |
Package contents (Standard)
- Microstep driver unit : PDSA-BB
- Motor unit : PMSA-B60D5D
- Driver to motor cable (60cm) and connector set
- Operation manual
