Product Detail :

Line up

0.72 deg/step microstep driver and Stepping motor package

The package of 2 phase stepping motor and microstep driver enables to run the motor at 0.72 deg /step, same as 5 phase stepping motor. Maximum resolution is 25,600 ppr (0.0140625deg/step) Depending on the applications and torque requirement, motor is selectable from size 28mm(NEMA11),42mm(NEMA17) ,56.4mm(NEMA23) and 60mm(NEMA24) lineup.

Product Lineup

[ Single shaft type | Double shaft type ]



28	CSA-UB28D1	0.95	0.056	31.5	0.11
28	CSA-UB28D2	0.95	0.075	39.5	0.15
28	CSA-UB28D4	0.95	0.114	50.5	0.20
42	CSA-UB42D1	1.2	0.237	34.0	0.23
42	CSA-UB42D2	1.2	0.341	40.0	0.29
42	CSA-UB42D3	1.2	0.430	47.5	0.36
56.4	CSA-UB56D1	2.0	0.678	42.0	0.51
56.4	CSA-UB56D3	2.0	1.106	54.5	0.71
56.4	CSA-UB56D5	2.0	1.876	77.5	1.11
60	CSA-UB60D1	2.0	0.882	46.3	0.62
60	CSA-UB60D3	2.0	1.341	55.8	0.88
60	CSA-UB60D5	2.0	2.541	87.8	1.40

*Please refer the attention before starting download service
(2D data and 3 data are compressed by zip format)



28	CSA-UB28D1D	0.95	0.056	31.5	0.11
28	CSA-UB28D2D	0.95	0.075	39.5	0.15
28	CSA-UB28D4D	0.95	0.114	50.5	0.20
42	CSA-UB42D1D	1.2	0.237	34.0	0.23
42	CSA-UB42D2D	1.2	0.341	40.0	0.29
42	CSA-UB42D3D	1.2	0.430	47.5	0.36
56.4	CSA-UB56D1D	2.0	0.678	42.0	0.51
56.4	CSA-UB56D3D	2.0	1.106	54.5	0.71
56.4	CSA-UB56D5D	2.0	1.876	77.5	1.11
60	CSA-UB60D1D	2.0	0.882	46.3	0.62
60	CSA-UB60D3D	2.0	1.341	55.8	0.88
60	CSA-UB60D5D	2.0	2.541	87.8	1.40

*Please refer the attention before starting download service
(2D data and 3 data are compressed by zip format)

Specification detials

0.72 deg /step microstep driver & Stepping motor package

0.72 deg /step microstep driver : PDSA-UB

Run 2 phase motor with 5 phase motor's resolution
Maximum 25,600 pulse per revolution
(Minimum step angle :0.0140625 deg)
Selectable 16 microstep settings
(1/1,1/2,1/2.5,1/4,1/5,1/8,1/10,1/12,5,1/16,1/20,1/25,1/32,
1/40,1/50,1/64,1/128)
―Enable 0.72°/ 0.36°step angle setting
―Accurate step trace even 1 pitch step
CW / CCW limit input
Input voltage : DC24V
16 step running current setting : 0 - 3.0A(Max)
Auto pwer down function
Protecting function (Over current protections)

CSA-UB (2 phase) vs. 5 phase motor vibration comparison data

CSA-UB: Example of limit input usage

2 phase stepping motor

28mm(NEMA11) motor	42mm(NEMA17) motor	56.4mm(NEMA23) motor

Step angle	1.8deg
Winding type	unipolar
Shaft type	Single shaft / Double shaft
Rated current	0.95 - 2.0A

Packaged contents (Standard)

Microstep driver unit
Motor unit
Controller to motor cable (60cm)
Power supply cable (60cm)
Signal cable (60cm)
Operation manual
